Tympanometers TouchTymp RaceCar

The TouchTymp RaceCar is an advanced pediatric tympanometer designed to make middle ear testing fast, accurate, and engaging for children. Its interactive animated race car display keeps children focused during tympanometry and reflex screening procedures, reducing movement and minimizing retesting.

Key Features

• Interactive RaceCar animation for child-friendly testing
• Fast and accurate middle ear analysis
• Full touch-screen interface for intuitive operation
• Built-in thermal printer for instant result printing
• Customizable protocols and testing options
• Quick screen transitions with high-resolution display
• Reduces probe seal interruptions and retesting
• Suitable for clinics, hospitals, ENT specialists, and audiology centers

Tympanometry Specifications

• Probe Frequency: 226 Hz ±1%, 85 dB SPL
• Optional High Frequency: 1000 Hz ±1%, 69 dB SPL
• Pressure Range: -600 to +400 daPa
• Volume Range: 0.0 to 6.0 ml (compensated)
• Compliance Range:
  • 0.1 to 8.0 ml at 226 Hz
  • 0.1 to 15.0 mmho at 1000 Hz (optional)
• Test Time: Approximately 3–5 seconds
• Accuracy of Pressure: ±5% or ±10 daPa
• Accuracy of Volume: ±5% or 0.1 ml

Acoustic Reflex Features

• Test Frequencies:
  • 500 Hz
  • 1000 Hz
  • 2000 Hz
  • 4000 Hz
• Ipsilateral and optional contralateral testing
• Automatic or fixed level reflex testing
• Reflex intensity range:
  • Ipsilateral: 70 to 105 dB HL
  • Contralateral: up to 120 dB HL

Device Specifications

• 10.4-inch graphic LED touchscreen display
• Lightweight handheld probe with control light and switch
• USB PC connectivity
• Fast built-in thermal printer
• Power Supply: 100–240V AC
• Compact and portable design

Benefits

• Makes hearing assessments enjoyable for children
• Saves testing time for clinicians
• Provides reliable and quick diagnostic results
• Improves patient cooperation during testing
• Ideal for pediatric audiology and ENT screening

Applications

• Pediatric hearing screening
• Middle ear analysis
• Tympanometry testing
• Acoustic reflex testing
• Audiology clinics and ENT departments

The TouchTymp RaceCar combines modern audiology technology with an engaging child-focused design, making pediatric tympanometry easier, faster, and more comfortable for both clinicians and young patients.
