Description

Otowave 102 Screening Tympanometry

The Otowave 102 Screening Tympanometry is a compact and reliable handheld tympanometer designed for fast and accurate middle ear assessment. Ideal for audiologists, ENT specialists, hearing care centers, hospitals, and mobile screening programs, this advanced screening device delivers efficient tympanometry testing with user-friendly operation and excellent portability.

Its ergonomic handheld design, real-time graphical display, and automatic test evaluation make it especially suitable for screening children and adults for middle ear disorders such as otitis media (glue ear), Eustachian tube dysfunction, and conductive hearing loss conditions.

Key Features

• Fast and accurate middle ear measurements
• Portable and lightweight handheld design
• Large LCD graphical display for easy viewing
• Automatic Pass/Refer evaluation
• Programmable ipsilateral acoustic reflex testing
• Internal memory for storing patient results
• PC connectivity and NOAH-compatible data transfer
• Optional portable printer and IR data transfer
• Multiple language support
• Ergonomic design for comfortable daily use

Technical Specifications

• Probe Tone: 226 Hz ±2%
• Pressure Range: +200 daPa to -400 daPa
• Ear Canal Volume Range: 0.2 ml to 5 ml
• Reflex Test Frequencies:
  • 102-1: 1 kHz
  • 102-4: 500 Hz, 1 kHz, 2 kHz, 4 kHz
• Power Supply: 4 AA alkaline or rechargeable NiMH batteries
• Weight: Approximately 380 g
• Internal Memory: Stores up to 30 patient records

Clinical Applications

The Otowave 102 is widely used for:

• Middle ear screening
• Tympanometry testing
• Acoustic reflex assessment
• Pediatric hearing screening
• School and community hearing programs
• ENT and audiology clinics
• Mobile hearing healthcare services

Benefits

With its lightweight structure and rapid test capability, the Otowave 102 helps clinicians reduce consultation time while maintaining reliable diagnostic performance. The built-in memory and optional PC connectivity improve workflow efficiency by enabling seamless patient data storage and transfer.
